A black electronic device with multiple ports labeled GPS, LAN, VO, and PWR, used for connectivity and data transmission.

Geo-iNAV

A high-performance, ruggedized GPS-aided inertial navigation system

GPS + IMU COMBINED TO PROVIDE A PNT NAVIGATION SYSTEM

Geo-iNAV is a fully integrated GPS-aided inertia navigation system supporting a wide range of IMU grades and providing a high performance, trusted positioning, and navigation capability.

Applications

  • UAV, USV, and UGV navigation and control

  • Military and defense security

  • Robotic and ROV control

  • Oil and gas exploration

  • Transportation safety and maintenance

  • Mobile mapping systems and photogrammetry

  • Construction and structural management

Benefits

Centimeter-level position accuracy (RTK configuration)

  • GPS Processing with Precise Instantaneous Network positioning based on AEVEX’s Epoch – by – Epoch® technology

  • In-motion dynamic alignment

  • Support for low, medium, and high dynamic platforms

  • Post-processing support with RTD-Post

  • Mil-Spec ruggedization

  • Additional aiding sensors, such as barometers, Altitude Heading and Refence Systems (AHRS), odometers, etc, can also be integrated

  • Includes GPS antenna and cable

Specifications

  • Size / Weight / Power:

    • 8 in³ (4.73×3.95×1.81) / 20 oz. / 10 – 30 VDC @ 2 Amps min. (not including external IMU’s)

  • Temperature Range:

    • Specified: -20°C to +65°C

    • Operating: -40°C to +70°C

  • Real-Time Data Output

    • Navigation solutions at 125/200 Hz (MEMS), 100-400 Hz. (FOG, RLG). available via Ethernet, RS-232

  • Data Recording/Logging

    • Navigation solutions, raw GPS & IMU data

    • VYO Real-Time Navigation Visualization Tool as convenient interface to visualize time, position, attitude and related information (TSPI) streamed data

  • External IMU Support

    • Fiber Optic Gyro is standard in Advanced configurations. Built-in support for:

      • Honeywell HG1900, HG1700, HG9900

      • Litton LN200, Inertial Lab Fl200C

      • Emcore TAC -450

      • Other IMU’s available upon request
